Bucket volume m3： |
0.17±0.017m3 |
Technology Productivity |
≥30m3/h |
|
Loading width： |
≥1700mm |
Track Gauge mm |
≥1210mm |
|
Unloading distance： |
≥270mm |
Maximum working height |
1920mm |
|
Gauge： |
600mm |
Tread： |
850mm |
|
Transportation status Dimensions： |
2150mm×1550mm×1260mm |
Walking Power kw |
10.5KW |
|
Bucket Power kw： |
13KW |
Supply Voltage |
380V |
|
Mobile speed： |
≈0.85m/s |
Bucket lifting speed： |
0.46-0.71m/s |
|
Total mass： |
3200kg |
Electro-hydraulic pusher motor power： |
1.5KW (three-phase four-wire) |
|
Electro-hydraulic putt voltage： |
AC380V |
Hydraulic Oil Type： |
Winter HM-32 hydraulic oil Summer HM-68 hydraulic oil |
|
System rated working pressure： |
7MPa |
System test pressure： |
10MPa |
|
Hydraulic shovel motor fixed： Hydraulic pump fixed shovel： |
Y90S-4 1100W B5 YB1-4 |
Relief： Brake caliper： |
DBDH6G10/10/2 |
