model |
ZQ-17 |
|
|
Loading capacity m3/h |
20-30 |
|
|
Bucket volume m3 |
0.17 |
|
|
Maximum lifting height of bucket mm |
1975 |
|
|
Track gauge mm |
500 |
|
|
Kinetic energy |
Pneumatic |
|
|
Travel speed m/s |
1.14 |
|
|
Working air pressure |
0.45-0.7MPA |
|
|
Travel motor power kW |
9 |
|
|
Lifting bucket motor power kW |
15 |
|
|
Unloading height mm |
1260 |
|
|
Maximum loading width mm |
1910 |
|
|
Unloading distance mm |
550 |
|
|
Overall dimension mm |
Long (when the bucket is down) |
2230 |
|
Width (when the pedal is down) |
1360 |
|
|
Width (when the pedal is lifted) |
1090 |
|
|
Height (when in transit) |
1390 |
|
|
Machine weight kg |
|
2700 |
