Technical parameters:
|
No. |
Item |
Parameter |
|
1 |
Bucket capacity |
2 m³ |
|
2 |
Rated load |
4t |
|
3 |
Maximum shoveling force |
100KN |
|
4 |
Maximum drawbar pull |
104KN |
|
5 |
Maximum unloading height |
1740mm |
|
6 |
Minimum unloading distance |
880mm |
|
7 |
Unloading angle |
40° |
|
8 |
Minimum ground clearance |
256mm |
|
9 |
Departure angle |
16° |
|
10 |
Swing angle of rear axle |
±7° |
|
11 |
Minimum turning radius |
3060mm（inside） 6000mm（outside） |
|
12 |
Running speed |
First gear：0-3.6km/h |
|
Second gear：0-6.7km/h |
||
|
Third gear：0-11.3km/h |
||
|
13 |
Hydraulic torque converter |
C270（DANA） |
|
14 |
Power transmission |
R32365（DANA） |
|
15 |
Drive axle |
Rigid planetary drive axle of No-Spin anti slip differential |
|
16 |
Braking system |
Hydraulic release, spring brake |
|
17 |
Motor model / Power |
HM4-280-4/75KW |
|
18 |
Dimensions (length x width x height) |
7410×1810×2100mm |
|
19 |
Total Weight |
13.2t |
