Technical parameters:
|
No. |
Item |
Parameter |
|
1 |
Bucket capacity |
0.6 cubic meters |
|
2 |
Rated load |
1.2t |
|
3 |
Maximum shoveling force |
40 KN |
|
4 |
maximum drawbar pull |
38 KN |
|
5 |
Minimum unloading distance |
785 mm |
|
6 |
Maximum unloading height |
1020 mm |
|
7 |
Climbing ability (full load) |
25° |
|
8 |
最小转弯半径 Minimum turning radius |
3445 mm outside, 1900 mm inside |
|
9 |
Maximum steering angle (left/right) |
38° |
|
10 |
Departure angle |
16° |
|
11 |
Driving speed (two-way) |
0-7km/h |
|
12 |
Motor model/power |
HM2-2-225S-4/37kw |
|
13 |
Braking system |
Integrate working brake and parking brake, adopt spring brake, hydraulic release brake |
|
14 |
Dimensions (length x width x height) |
4750x1100x1840 mm |
|
15 |
Total Weight |
5.1t |
