No. |
Item |
Parameter |
|
1 |
Bucket capacity |
1m³ |
|
2 |
Rated load |
2t |
|
3 |
Maximum shoveling force |
48KN |
|
4 |
Maximum drawbar pull |
45KN |
|
5 |
Minimum unloading distance |
820mm |
|
6 |
Maximum unloading height |
1120mm |
|
7 |
Climbing ability (full load) |
12° |
|
8 |
Minimum turning radius |
4260 mm outside, 2420 mm inside |
|
9 |
Maximum steering angle (left/right) |
38° |
|
10 |
Departure angle |
15° |
|
11 |
Driving speed (two-way) |
0-9km/h |
|
12 |
Engine model / Power |
61.5KW/2200R |
|
13 |
Braking system |
Integrate working brake and parking brake, adopt spring brake, hydraulic release brake |
|
14 |
Dimensions (length x width x height) |
5960x1420x2000mm |
|
15 |
Total Weight |
7.3t |
